Taitong FX 7" Background Music Control Panel
Model FX
Works withTuyaMi HomeTmall GenieMatterKnx
7-inch control panel supporting the universal (Fan Zhi Lian) protocol
Specifications
| Expansion | Distance sensor / interface available for custom control panels |
|---|---|
| System | Android 8.1, RAM 1GB, ROM 8GB |
| Display | 7-inch display, 1024×600, capacitive touch screen |
| Built-in Speaker | 1W |
| ITO Platform | Tuya ZigBee / Tmall |
| Speaker Output | 2×(10-25)W digital amplifier |
| Power Supply | 90V-240V |
| Audio | 1 input; 1 output |
| RS-485 Port | 1 output |
| Mounting | Single 86-type back box |
| Bluetooth | Receive / transmit (for Bluetooth speakers) |
| Weight | 1.1KG |
| External Ports | TF card, USB port |
| Dimensions | 214.6×111.6×11.5MM |
