Taitong Dual-Channel 0-10V Bluetooth Controller
For domestic and commercial installations that need scene control and independent luminaire control. Communication is over Bluetooth — no signal wiring or complex addressing — so configuration is straightforward. The device connects directly to the phone app or works alongside other Bluetooth devices, supporting single-device, group and scene-cluster control.
Specifications
| Product Name | 0–10V Bluetooth controller |
|---|---|
| Model | IN-BLE-DIM-10V2 |
| Wireless Type | Bluetooth mesh communication |
| Input Voltage | 110-240Vac |
| Output Current | 0–30mA (output 1); 0–30mA (output 2); 1A (input) |
| Output Voltage | 0-10 V |
| Operating Temperature | -20~ +50℃ |
| Load Power | < 100W (input side) |
| Surge Withstand | 1kv |
| Leakage Current | <700 uA |
| Storage Temperature / Humidity | -40℃ ~ +80℃ |
| Dielectric Strength | 3750V / 1 minute |
| Safety Standards | EN61347&EN62384 |
| Dimensions | 109*31*22.5mm |
| Weight | 56.0 g |
